SIZE & SPECIFICATIONS

SIZE & SPECIFICATIONS

      BOLT CENTER   MAX WEIGHT
SIZE FINISH STYLE PATTERN BORE OFFSET LOAD LBS
8x3.75 White Stamped 4 on 4 2.82 0 900 4.4
8x3.75 Galvanized Stamped 4 on 4 2.82 0 900 4.4
8x3.75 White Stamped 5 on 4.5 2.82 0 900 4.4
8x3.75 Galvanized Stamped 5 on 4.5 2.82 0 900 4.4
8x5.375 White Stamped 4 on 4 2.82 0 / 3.5+1.875 900 5.1
8x5.375 Galvanized Stamped 4 on 4 2.82 0 / 3.5+1.875 900 5.1
8x5.375 White Stamped 5 on 4.5 2.82 0 / 3.5+1.875 900 5.1
8x5.375 Galvanized Stamped 5 on 4.5 2.82 0 / 3.5+1.875 900 5.1
8x7 White Stamped 4 on 4 2.82 0 900 5.9
8x7 Galvanized Stamped 4 on 4 2.82 0 900 5.9
8x7 White Stamped 5 on 4.5 2.82 0 900 5.9
8x7 Galvanized Stamped 5 on 4.5 2.82 0 900 5.9
10x6 White Stamped 4 on 4 2.82 0 1200 9.2
10x6 Galvanized Stamped 4 on 4 2.82 0 1200 9.2
10x6 White Stamped 5 on 4.5 2.82 0 2000 9.2
10x6 Galvanized Stamped 5 on 4.5 2.82 0 2000 9.2
10x6 HD White Stamped 6 on 6 4.65 0 2500 11.9
10x7 White Stamped 4 on 4 2.82 3+4 1200 10.1
10x7 Galvanized Stamped 4 on 4 2.82 3+4 1200 10.1
10x7 White Stamped 5 on 4.5 2.82 3+4 2000 10.1
10x7 Galvanized Stamped 5 on 4.5 2.82 3+4 2000 10.1
10x8 White Stamped 4 on 4 2.82 3+5 1200 11.0
10x8 Galvanized Stamped 4 on 4 2.82 3+5 1200 11.0
10x8 White Stamped 5 on 4.5 2.82 3+5 2000 11.0
10x8 Galvanized Stamped 5 on 4.5 2.82 3+5 2000 11.0

Other color e-coated finish is available by special order.
